The Functions of Blowout Preventers - Houston

In the oil and gas industry, a leaky well could spell disaster. Not only will repairs cost the company money, but the spilled oil is dangerous to workers and wildlife alike. Fortunately, helpful devices known as blowout preventers prevent this disaster from happening.

Want more information on blowout preventer price? Feel free to contact us.

Simply put, blowout preventers (BOPs) keep the oil well safely sealed to prevent damages and revenue loss. Various types of BOPs serve slightly different purposes and may help with a certain type of oil well problem more than another. Before you decide which type you need, you must first understand what each type does.

A blowout preventer for your oil well will make a huge difference. Learn which kind you need here.

Annular BOPs

An annular blowout preventer is a large, specialized BOP used to seal, control and monitor oil and gas wells. It is usually installed above the ram preventers that forms a seal in the annular space between the pipe and wellbore or, if no pipe is present, over the wellbore itself.

RAM BOPs

A RAM BOP seals the well itself, preventing oil from escaping and foreign materials from getting in. It also allows for a controlled flow of oil when necessary. Depending on your needs, you may also find these variants on a standard RAM BOP useful:

• Kill line valves

• Choke line valves

• Blind RAMs

• Choke manifolds

Pro Tip: Some RAM BOPs include an option for remote operation! See if the model you need allows remote work.

API Equipment

These crucial parts for BOPs include flanged crosses, drilling spools, male and female adapters, and more for building and repairing quality BOPs. The equipment can be customized to fit whatever you may need for a BOP. Whether you’re repairing an old blowout preventer or customizing a new one to your oil well, quality API equipment has you covered.

Contact us to discuss your requirements of blowout preventer companies. Our experienced sales team can help you identify the options that best suit your needs.

Preventing Oil Well Blowouts

The basic function of a blowout preventer is, of course, to prevent an oil blowout. But each part of the overall BOP serves an important purpose in maintaining a seal over the well opening. Make sure you have all the equipment you need before assembling a full BOP.

Connect with us to learn more about blowout prevention and oil well safety.

Before the development of blowout preventers, operators allowed pressured fluids to flow uncontrolled from formations to the surface and into the atmosphere. Only after the pressure supporting these blowouts abated and surface pressures fell to a manageable level were rig workers able to cap the well. Blowouts were dangerous for the crew, threatened the well-being of the surrounding environment, damaged drilling equipment, wasted resources and caused irreparable harm to the producing zone.

In 1922, Harry Cameron and Jim Abercrombie designed and manufactured the first blowout preventers (BOPs). Assemblies of valves and other devices installed atop a wellhead during drilling operations are called BOP stacks; they provide a means by which rig crews are able to contain unexpected flow and high pressures. They allow crews to manage these influxes by injecting dense fluids down the well, which stop, or kill, the flow of formation fluids; this kill operation is accomplished while preventing well fluids from being released into the atmosphere.

Within the E&P industry, the terms blowout preventer, BOP stack and blowout preventer system are used interchangeably. During drilling and completion operations, they are the second barrier to formation flow; hydrostatic pressure at the formation created by a column of drilling fluid and zonal isolation provided by casing and cement constitute the primary barrier.

The individual BOPs that constitute a system are stacked vertically atop the well. They are aligned to allow access through them into the wellbore while their various functions provide a variety of methods for sealing the well during drilling, completion or intervention operations. They are sized to fit the internal diameter of the wellhead and expected surface pressures.

Blowout preventer stacks typically include annular BOPs and ram-type BOPs. Annular BOPs were introduced to the industry in 1946 by Granville Sloan Knox. These devices force circular steel-reinforced rubber elements to close on and create a seal around drillpipe or other tools that may be in the wellbore at the time of shut-in (Figure 1). When annular BOPs are shut in around a pipe, the pipe may be moved up or down or rotated without breaking the seal. Designed to prevent flow up the casing-drillpipe annulus, annular BOPs are also able to seal a clear wellbore in which no obstruction is present although doing so reduces the rated working pressure of the sealing element by 50%.

Ram-type BOPs include rubber-faced steel rams that are brought together to create a seal or, like annular BOPs, form a seal around a tool in the wellhead (Figure 2). Shear rams are high-strength hydraulically powered rams that are able to sever drillpipe. They include casing shear rams and blind shear rams. Both are designed to cut drillpipe or other obstructions in the well. Blind shear rams can completely seal the well. Casing shear rams, while not able to form a seal, typically are able to cut larger size tubulars than those that blind shear rams can cut.

Drillers use a control system to actuate rams that is comprised of accumulator bottles containing pressurized hydraulic fluid, a hydraulic fluid storage reservoir, a pumping system and hydraulic piping. The hydraulic fluid is directed to a desired function on the BOP stack via a remote control panel.

Are you interested in learning more about blow out preventer manufacturer? Contact us today to secure an expert consultation!
