1.0619 Globe Check Valve

Author: Minnie

Apr. 29, 2024

1.0619 Globe Check Valve

Product Description

Click here to get more.

1.0619 Globe Check Valve

Applicable Standards:
Design EN 13709
Face to face EN 558-1
End Flanges EN 1092-1
Butt Welding ends EN 12627
Inspection and test EN 12266-1

Material: 1.0619
Size Range: DN15~DN400
Pressure Rating: PN16, PN25, PN40
Temperature Range: -50°C~650°C

Design Description:
-Straight pattern
- Outside Screw and York
- Bolted Bonnet
- Seat in stellite or 13%Cr
- Available with gear operator
- Flange Ends
- Butt-welding Ends

Brand DIDTEK Structure Globe Check Valve Material Didtek provide cast steel, stainless steel, special alloy, CI, DI etc Valve Type Didtek Produce Globe Check Valve Valve Test 100% quantity tested before delivery Valve Guarantee 18 months after shipments and 12 months after installed Valve Structure Globe Check Valve Valve Delivery 15 - 30 days Valve Sample Sample Available by Didtek Valve Valve Color Customer request Valve Packing Plywood Case for Globe Check Valve MOQ 1 Set Valve Certificate API6D/CE/ISO9001/ISO14001 Place of Origin Zhejiang, China (Mainland) Delivery Detail: Shipped in 15-30 days after payment Port Shanghai Or Ningbo Payment Terms L/C,D/A,D/P,T/T, Western Union

Application & Function:
Didtek DIN Globe Check Valve structure is similar to globe valve, but the connection of stem and disc are not fixed. The globe check valve could run globe valve fuction when the stem drops and compresses the disc on the seat, while when the stem rises up, it could work as a check valve. When we need to install both globe valve and check valve on the pipe at the same time, or with limited installation area(e.g.ships),the globe check valve would be the best choice as it could save installation cost as well as space.

It is used for throttling flow control. Shut off is accomplished by moving the disc against the flow stream rather than across it as in the case with a gate valve. The flow pattern through a globe valve involves changes in direction, resulting in greater resistance to flow, causing high pressure drop. The globe valve is an excellent valve to use for on-off service, but is highly suited for frequent cycling and control of fluids anywhere in amount or volume between the open and closed positions.

The Globe Check valve must be installed in the proper relation to the media flow as indicated by the flow direction arrow marked on the valve body. This valve is considered uni-directional and must be installed with the pressure side or inlet under the seat.

LEFLOW are exported all over the world and different industries with quality first. Our belief is to provide our customers with more and better high value-added products. Let's create a better future together.

Related links:
Buy Valves | Valve Types & Valve Suppliers
Comprehensive Guide: Maintaining Pneumatic Valves for Optimal Performance
What Is A Top Entry Ball Valve?
What is the difference between resilient seated and metal seated gate valves?
What is the difference between a gate valve and a wedge valve?
When Should You Use Cartridge Valves?
What is the difference between 2pc and 3pc ball valves?

Accessories:
Gear operators, actuators, locking devices, chain wheels and So on, extended stems and bonnets for cryogenic service and many others are available to meet the customer’s requirements.

SSC Swing Check Valve

Swissfluid fully lined SSC Swing Check Valves are designed specifically for applications with highly corrosive media. They can replace similar valves made from exotic – and expensive – alloys. This valve is suitable for horizontal and vertical piping systems thanks to its ingenious construction where the disc is in full contact with the housing in horizontal applications. Additionally, the disc comes with a precision-machined lip which helps achieve leak-free sealing with minimal pressure differential, and its full-bore lined SS disc snaps into place in the lined body and cannot drop out during installation.

The state-of-the-art design of our SSC Swing Check Valve allows easy and accurate positioning of our valve in ANSI as well as DIN piping systems with the fully integrated centering lugs. An additional, easily accessible drill hole situated between the centering lugs further facilitates installation of larger sizes. Minimum pressure loss is achieved by the large opening angle of the disc in our Swing Check Valve.

The standard lining material for our Swing Check Valves is highly permeation-resistant PFA or PFA-AS (anti-static). Options include solid metal discs made from SS316L, Titanium Gr. 2 and Hastelloy-C. Fluoroplastic linings of the body and fully encapsulated disc are mechanically-locked assuring form-stable adhesion over the entire application range, which is critical in high temperatures or vacuum conditions.

Our standard body material is ASTM A-216 WCB (1.0619). AISI A316 stainless steel (CF-8M / 1.4408) bodies can be furnished also, for service in corrosive atmospheres. Our Swing Check Valves are available wafer style; however, for heavy-duty applications flanged lug connections are available on request. Face-to-face dimensions are in accordance with EN 558-1 row 20.

Not only do SSC Swing Check Valves distinguish themselves with their quiet operation, they are also maintenance-free and can be used with differential pressure up to 10 bar (145psi) in temperatures ranging from -40°C (-40°F) to 200°C (392°F).

The self-sealing disc protects the system from pressure surges common in longer piping systems, and acts as an excellent barrier to the unintended draining of media in piping systems during maintenance and repair work.

Main features

- Wafer-style body, two- and three-piece, DIN/ANSI combined
- Centering lugs for safe installation
- Tilted disc (to shut by gravity even when pipe isn't completely level)
- Self-retaining disc, no counter flanges needed to hold the disc in place
- Horizontal or vertical installation
- Integrated sealing lip (to seal at low differential pressures)

The company is the world’s best 1.0619 swing check valve supplier. We are your one-stop shop for all needs. Our staff are highly-specialized and will help you find the product you need.
